ILITEK tech 10.1'' Touch LCD Module

Time:2022-05-19 Source: https://youtu.be/ycgoVH2yCuA Author: https://youtu.be/ycgoVH2yCuA Reading: 699



Part Number: JT101TM006-V1.0

Brand: JUTOUCH
Size: 10.1 inch

Active Area(mm): 216.96 × 135.6

Viewing Area(mm): 217.96 × 136.6

Outline Size(mm): 210.08 × 146.72 × 4.10

Brightness: 1000 nits

LCD Type: 10.1"TFT, Transmissive Normally Black

Resolution: 1280 × 800

Driver IC: ILI2511

LCD Interface: LVDS

Connection type: COF

Structure: G+G, Optical bonding

Cover glass =2.8mm, Chemical strengthen

Sensor glass Thickness=0.55mm

Surface treatment: AG+AF

TP Interface: USB, Touch Point: 10




The 3D drawing





Welcome to book standard or customized touch and LCD from Jutouch!
