27 Inch Industrial PCAP Touch Screen LCD Display Module JT270TM001-V1 with HDMI

The JT270TM001-V1 with HDMI is a 27.0-inch industrial PCAP touch screen LCD display module from JuTouch Technology. It features a 27.0" TFT-LCD with Full HD resolution of 1920 x 1080 (RGB) and a G+G+G+LCD structure with OCA bonding, ensuring robust durability and optical clarity. The display delivers high brightness of 1100 cd/m² (Min) to 1250 cd/m² (Typ) with CTP, making it suitable for demanding industrial and commercial applications. It supports an operating temperature range of -20°C to +60°C and a storage temperature range of -30°C to +70°C. The LCD interface is LVDS (2ch), while the CTP interface supports USB, I2C, and RS232. Additional specifications include a thermally tempered soda-lime cover glass, surface hardness ≥6H, CTP IC EXC81H84 with TX64*RX36 and COB connection, RoHS compliance, and a general tolerance of ±0.5. This module is ideal for industrial control, medical, kiosk, and embedded systems requiring a reliable, high-brightness touch display with HDMI support.
