19.7-inch FHD TFT-LCD Display Module (LVDS Interface, 700 nits, 1920x624)

The JT197FHI30R7L01 is a 19.7-inch color active matrix TFT-LCD module featuring an FHD resolution of 1920 x 624 pixels. With a typical brightness of 700 cd/m², it delivers clear and vivid visuals, making it perfectly suited for industrial HMI panels, digital signage, and public information displays in semi-outdoor environments.

This module utilizes an LVDS interface (2-pixel/clock) and supports both landscape and portrait orientations. It displays 16.7 million colors with high contrast and wide viewing angles. The integrated edge-type LED backlight ensures energy efficiency and long lifespan. Designed for durability, it operates reliably within a wide temperature range of -20°C to 70°C and complies with RoHS and Halogen-Free environmental standards.

DOWNLOAD SPECS
